Euchner TZ1LE024BHA-C2399 Safety Switch 119367 240VAC 10W
Brand: Euchner | Model: TZ1LE024BHA-C2399 | Condition: New Factory Sealed | NEO SKU: 15459-1
Original price was: $941.20.$751.92Current price is: $751.92.
1 in stock
Free Shipping on orders over $50.
*(Domestic only)
Need it fast? Next Day Air available at check out.
Same Day Handling on orders prior to 2pm Eastern Monday – Friday
1 in stock
NEO SKU: 15459-1 | Category: Safety Relays
Euchner TZ1LE024BHA-C2399 Safety Switch 119367 240VAC 10W - New Factory Sealed
Product Details
Condition: New Factory Sealed
Brand: Euchner
Model: TZ1LE024BHA-C2399
MPN: 119367
Electrical
Input
Volts: 240VAC
Watts: 10W
UPC: 119367000224
Country of Origin: Germany
MFG Product Notes
Operating and display elements: In-line
LED display: Operating voltage corresponds to the solenoid voltage
Electrical connection values: Check
Fuse: max. 4 A gG
Power consumption: 10 W
Rated insulation voltage Ui: 250 V
Rated impulse voltage Uimp: 1.5 kV
Utilization category:
DC-13: 4 A 24 V
AC-15: 4 A 230 V
Solenoid operating voltage:
AC/DC: 24 V -15% … +10%
Solenoid duty cycle: 100 %
Switching voltage:
min. at 10 mA: 12 V
Switching current:
min. at 24 V: 1 mA
thermal rated current Ith: 4 A
Mechanical values and environment: Free Flow in one direction shut-off in reverse
Anfahrgeschwindigkeit: max. 20 m/min
Approach direction:
Actuating head left: C
Connection type:
1 x: Plug connector BHA10
Number of door position positively driven contacts: 4
Number of guard lock monitoring positively driven contacts: 4
Extraction force: 30 N
Actuation frequency: max. 1200 1/h
Actuating force: 35 N
Lid: red
Installation orientation: any
Insertion depth: 52 mm
Storage temperature: -25 … 80 °C
Mechanical life: 1 x 10⁶
Retention force: 10 N
Switching principle: Slow-action switching contact
Degree of protection: IP65
Ambient temperature: -25 … 80 °C
Material:
Contact: Silver alloy, gold flashed
Housing: Anodized die-cast alloy
Locking force Fmax: 2000 N
Locking force FZh: 1500 N
Guard locking principle: Closed-circuit current principle
MFG Description
Euchner manufactures high-quality safety switches and automation components, providing reliable solutions for machine safety and industrial automation applications.
MFG URL
For more information about this product or Euchner, check out their website: https://euchner.com
Only logged in customers who have purchased this product may leave a review.
Additional information
| Weight | 5 lbs |
|---|---|
| Dimensions | 11 × 11 × 11 in |
| Condition | New Factory Sealed |
| Brand | Euchner |
| Model | TZ1LE024BHA-C2399 |
| MPN | 119367 |
| Input Volts | 240VAC |
| Input Watts | 10W |
| Origin | Germany |
| UPC | 119367000224 |
Euchner TZ1LE024BHA-C2399 Safety Switch 119367 240VAC 10W
Product Details
NEO SKU: 15459-1
Condition: New Factory Sealed
Brand: Euchner
Model: TZ1LE024BHA-C2399
MPN: 119367
Description: Safety Switch
Input Volts: 240VAC
Input Watts: 10W
Origin: Germany
UPC: 119367000224
Manufacturer Notes: Operating and display elements: In-line
LED display: Operating voltage corresponds to the solenoid voltage
Electrical connection values: Check
Fuse: max. 4 A gG
Power consumption: 10 W
Rated insulation voltage Ui: 250 V
Rated impulse voltage Uimp: 1.5 kV
Utilization category:
DC-13: 4 A 24 V
AC-15: 4 A 230 V
Solenoid operating voltage:
AC/DC: 24 V -15% … +10%
Solenoid duty cycle: 100 %
Switching voltage:
min. at 10 mA: 12 V
Switching current:
min. at 24 V: 1 mA
thermal rated current Ith: 4 A
Mechanical values and environment: Free Flow in one direction shut-off in reverse
Anfahrgeschwindigkeit: max. 20 m/min
Approach direction:
Actuating head left: C
Connection type:
1 x: Plug connector BHA10
Number of door position positively driven contacts: 4
Number of guard lock monitoring positively driven contacts: 4
Extraction force: 30 N
Actuation frequency: max. 1200 1/h
Actuating force: 35 N
Lid: red
Installation orientation: any
Insertion depth: 52 mm
Storage temperature: -25 … 80 °C
Mechanical life: 1 x 10⁶
Retention force: 10 N
Switching principle: Slow-action switching contact
Degree of protection: IP65
Ambient temperature: -25 … 80 °C
Material:
Contact: Silver alloy, gold flashed
Housing: Anodized die-cast alloy
Locking force Fmax: 2000 N
Locking force FZh: 1500 N
Guard locking principle: Closed-circuit current principle
